EC-6001C 5G Wifi Conference Chairman Unit 5inch screen
Code: EC-6001C
5G Wifi Conference Chairman Unit 5inch screen EC-6001C Port usage instructions 1、Square microphone, used for speech pickup. When the mic is open, it will be red, and when the delegate applies to speak, it will be green. 2、Only the chairman mic has the priority function, which can close the delegate that is speaking. 3、Speaking on and off buttons. 4、Service application button, which can be clicked when any service is needed in the meeting. 5、5.0-inch high-definition full-color display screen, which displays status information of meeting, battery power and signal indication. Support voting, election and rating. 6、3.5mm headphone jack, can input audio source. 7、Type-C interface can charge the unit. At the same time, it can upgrade the program and configure the parameter, support the fast charging function, and it can be fully charged in 3 hours. Charging indicator light, red and green light, show red when charging, and green when full. 8、Power button, click to turn it on, and press and hold for 3S to turn it off. When the unit is off, click for 4 times continuously to enter the setting SSID interface. 9、USB interface, used for extended functions. Features ■Exquisite and elegant structural design, ergonomic and modern. ■It has the function of intelligent fault detection, reminding users of AP fault, host communication fault, low signal strength and so on. ■Wireless mobile makes the desktop cleaner. ■Touch screen for convenient operation and rich content display. ■Original digital audio processing and transmission technology. ■Full digital audio technology, built-in high-performance CPU, faster processing speed and better sound quality. ■Support 48 kHz audio sampling frequency, and the frequency response can reach 80 Hz~16 kHz. ■All-digital audio transmission technology is adopted between different conference units, and between conference units and host. ■The system has automatic repair function and supports "hot plug" of lines. ■With microphone on-off key ■Gain and equalization can be adjusted independently (5 segments); Different volume and frequency response can be adjusted according to the voice characteristics of different speakers until the perfect effect is achieved. ■Electret heart-shaped directional microphone with two-color turn-on indicator ring ■Built-in microphone wind shield ■The microphone pole can be disassembled during recess, which is convenient for equipment maintenance. ■With key sign-in function ■Exquisite and fashionable 5.0'' touch screen is used to display the meeting progress information, which can display the following information: * List of speeches, countdown to speeches, and information of speakers. ■Super anti-interference ability of mobile phone ■The conference unit has a unique serial number, and the conference system can automatically or manually assign an ID to the conference unit. ■When not connected to a computer and used as a basic conference system, the following functions can be realized: * speaker number limit function, which can set up delegate units that can be opened at the same time. ■With the camera and video matrix, can achieve automatically tracking function after computer preset. ■Have the following conference control functions * When the total number of turned-on microphones is less than 6, press the microphone on key to directly turn on the microphone. * With the priority button, you can turn off or temporarily mute the delegate unit that is speaking according to the preset mode. * has the function of approving/rejecting the delegate's request to speak. ■3.5 mm stereo jack can connect headphone, and the volume can be adjusted. ■Adopt 128-bit AES encryption technology, support WPA/WPA2 wireless security technology, prevent eavesdropping and unauthorized access, and provide higher confidentiality of conference system. Specification 1. Microphone type: heart-shaped directional electret 2. frequency response: 80Hz~16KHz 3. Microphone input impedance: 1KΩ 4. Sensitivity:-43±1.5 DBV/PA 5. Maximum SPL: 100 dB (THD > 3%) 6. Signal-to-noise ratio: > 80dB(A) 7. Crosstalk: > 70dB 8. Dynamic range: > 80dB 9.THD： Connection Inlustraction:
