أنظمة الصوت / أنظمة نداء عام بتحكم رقمي
8-Channel Pre-Amplifier
الكود: EC-8PA
The EC-8PA is a versatile pre-amplifier with 8 line/mic inputs,1 emergency input and 1 microphone input on the front panel EMC is priority input, automatically muting all other signal inputs. MIC on the front panel has the highest priority, able to suppress all other inputs. With automatic mute function for paging Can adjust the volume of 8-Channel input and the Mic input independently
المواصفات الفنية
Model
EC-8PA
Input Channel
10 Channel(8-Line/Micㄛ1-EMCㄛ1-MICㄘ
Output Channel
8 Channels
Frequency Response
20Hz~20KHz
SNR
MIC: 65Db, LINE: 85dB
Power Consumption
20W
Power Supply
AC220V/50Hz
Product Size
485℅357℅88mm
Net Weight
4Kg
الاستخدامات
The EC-8PA is a versatile pre-amplifier with 8 line/mic inputs,1 emergency input and 1 microphone input on the front panel
EMC is priority input, automatically muting all other signal inputs.
MIC on the front panel has the highest priority, able to suppress all other inputs.
With automatic mute function for paging
Can adjust the volume of 8-Channel input and the Mic input independently
