EC-2500DP 2CH 500W Class-D Amplifier with DSP

الكود: EC-2500DP

2CH 500W Class-D Amplifier with DSP EC-2500DP Features: 1. Switching power technology digital power amplifier 2. Class-D PA power amplifier of minimum power consumption 3. Less rack space and less heat generation 4. Two channel power amplifier into 19” rack mount unit 5. Rated power output at 120W, 240W, 350W to 500W by two channels 6. Two channel separate speaker outputs 8Ω/100V/70V 7. Balanced XLR input by phoenix connector for two channels 8. Each input with separate gain control. 9. Each channel with high-cut filter 10. Built-in auto standby feature to save power consumption 11. Separate channel indicators for protection, clip, input and output 12. Complete short circuit, overload, high temp, clip and DC protection 13. Wide AC input from 110V to 240V input 14. DC 24V battery input at order request with additional cost Description: The FA range digital class-D power amplifier is of switching power technology, which features of minimum power consumption and much higher efficiency up to 85%, moreover it helps to save installation rack space, generate less heat so as to extend its performance life span as a result. The digital class-D amplifiers are of rated power output at 120W, 240W, 350W & 500W by two channels, so it could be used as two zone multiple sources public address system at minimum cost. The versatile loudspeaker outputs of both high impedance 100V/70V & low versatile loudspeaker outputs of both high impedance 100V/70V & low stereo sound installation jobs. There are two balanced inputs by phoenix connector for each There are two balanced inputs by phoenix connector for each There are two balanced inputs by phoenix connector for each filters could be enabled or disabled through the dip switch pre-setting. Automatic standby enable after no detection of signal input for one Automatic standby enable after no detection of signal input for one status indicators include protection, clip, input and output for easy supervision. With complete short circuit, overload, high temp, clip and DC protection. Wide AC power supply from 110V to 240V, thus it support worldwide sound system installation. DC24V battery input is optional at request. Specification: v:* {behavior:url(#default#VML);}o:* {behavior:url(#default#VML);}x:* {behavior:url(#default#VML);}.shape {behavior:url(#default#VML);} Model EC-2120DP EC-2240DP EC-2350DP EC-2500DP Description Class-D Two Channel Power Amplifier with DSP Rated Power Output 2*120W 2*240W 2*350W 2*500W Speaker Output 4-16Ω & 100V Frequency Response L/H Cut OFF 20Hz-20KHz (+1/-2dB) L/H Cut ON 70Hz-10KHz (+1/-3dB) Input 0.775V, 0dBu, balanced phoenix connector Input Impedance 10KΩ THD S/N Ratio >80dB Crosstalk >60dB, 1KHz, Max output Power Consumption 300W 550W 800W 1100W Power Supply AC input switchable between 115V & 230V, 50-60Hz 24V DC input as option at order request. Dimension 482(W)x420(D)x44(H) mm Weight 7.0kg 7.5kg 8KG 8.5KG
